removed accidental test files

demos/stefan/webxr/opencv-usage.js

@@ -0,0 +1 @@
+import cv from 'https://lively-kernel.org/lively4/aexpr/src/external/opencv/opencv-4.5.0.js'

demos/stefan/webxr/opencv-usage.md

@@ -0,0 +1,224 @@
+# OpenCV.js Test
+
+<script>
+import cv from 'https://lively-kernel.org/lively4/aexpr/src/external/opencv/opencv-4.5.0.js'
+import {run} from './opencv-usage.js';
+</script>
+
+<video id='videoInput' width='320' height='240' autoplay style='position: relative; display: inline-block;'></video>
+
+<div id='log'>starting</div>;
+
+<canvas id='canvasInput' width='320' height='240'></canvas>
+<canvas id="outputCanvas" width='320' height='240' style='border: red 1px solid;'></canvas>
+<canvas id="outputRect" width='320' height='240' style='border: red 1px solid;'></canvas>
+
+<canvas id="output" width='320' height='240' style='border: red 1px solid;'></canvas>
+
+![hello](https://lively-kernel.org/lively4/aexpr/demos/stefan/webxr/schierke.png){id=turtok}
+<canvas id="turtokOut" width='320' height='240' style='border: red 1px solid;'></canvas>
+
+<script>
+async function run() {
+  const get = id => lively.query(this, '#' + id)
+
+  let video = get("videoInput"); // video is the id of video tag
+  let canvasInput = get("canvasInput"); // canvasInput is the id of <canvas>
+  let outputCanvas = get('outputCanvas')
+  let matchesDebugRenderingOutputCanvas = get('output')
+
+  let videoAccess;
+  videoAccess = navigator.mediaDevices.getUserMedia({ video: true, audio: false })
+    .then(function(stream) {
+    video.srcObject = stream;
+    video.play();
+  })
+    .catch(function(err) {
+    console.log("An error occurred! " + err);
+  });
+
+  const turtok = get('turtok');
+  const turtokOut = get('turtokOut');
+
+  await cv['onRuntimeInitialized'];
+  await videoAccess.then(() => lively.sleep(1000))
+
+  const log = get('log')
+
+  {
+    // prep dataset
+    let referenceImage = cv.imread(turtok);
+    let refAnno = new cv.Mat();
+    cv.cvtColor(referenceImage, refAnno, cv.COLOR_RGBA2GRAY, 0);
+
+    let referenceKeypoints;
+    let referenceDescriptors;
+    let requestId;
+
+    const orb = new cv.ORB();
+    referenceKeypoints = new cv.KeyPointVector();
+    referenceDescriptors = new cv.Mat();
+    orb.detect(refAnno, referenceKeypoints);
+    orb.compute(refAnno, referenceKeypoints, referenceDescriptors);
+    // log.innerText = referenceKeypoints.size()
+
+    // refAnno
+    const color = new cv.Scalar(255, 255, 0, 255);
+    cv.drawKeypoints(refAnno, referenceKeypoints, refAnno, color);
+    for (let i = 0; i < referenceKeypoints.size(); ++i) {
+      const kp = referenceKeypoints.get(i);
+      const center = new cv.Point(kp.pt.x, kp.pt.y);
+      cv.circle(refAnno, center, 5, new cv.Scalar(0, 255, 0, 255), 1, cv.LINE_AA);
+    }
+    cv.imshow(turtokOut, refAnno);
+
+    // loop the vid capture
+    const cap = new cv.VideoCapture(video);
+    const processVideo = () => {
+      const newOrb = orb.clone()
+
+      const src = new cv.Mat(video.height, video.width, cv.CV_8UC4);
+      const gray = new cv.Mat();
+      const matcher = new cv.BFMatcher(cv.NORM_HAMMING, true);
+
+      cap.read(src);
+      cv.imshow(canvasInput, src);
+
+      cv.cvtColor(src, gray, cv.COLOR_RGBA2GRAY, 0);
+
+      // Detect ORB features
+      const keypoints = new cv.KeyPointVector();
+      const descriptors = new cv.Mat();
+      newOrb.detect(gray, keypoints);
+      newOrb.compute(gray, keypoints, descriptors);
+
+      log.innerText = `frame start`
+
+      const matches = new cv.DMatchVector();
+      matcher.match(referenceDescriptors, descriptors, matches);
+
+      // Draw matches
+      const output = src.clone();
+      cv.drawMatches(referenceImage, referenceKeypoints, gray, keypoints, matches, output, new cv.Scalar(0, 255, 0, 255), new cv.Scalar(255, 0, 0, 255));
+
+    // Filter matches
+    let goodMatches = [];
+    for (let i = 0; i < matches.size(); i++) {
+      if (matches.get(i).distance < 50) { // You can adjust the threshold
+        goodMatches.push(matches.get(i));
+      }
+    }
+
+      log.innerText += `, ${goodMatches.length} good`
+
+      // Draw keypoints
+      const color = new cv.Scalar(0, 255, 0, 255);
+      cv.drawKeypoints(src, keypoints, src, color);
+      for (let i = 0; i < keypoints.size(); ++i) {
+        const kp = keypoints.get(i);
+        const center = new cv.Point(kp.pt.x, kp.pt.y);
+        cv.circle(gray, center, 5, new cv.Scalar(0, 255, 0, 255), 1, cv.LINE_AA);
+      }
+
+      // Draw matches
+      const output2 = src.clone();
+      if (goodMatches.length > 10) { // Minimum number of good matches to consider the reference image found
+        // Extract location of good matches
+        const srcPoints = [];
+        const dstPoints = [];
+        for (let i = 0; i < goodMatches.length; i++) {
+          srcPoints.push(referenceKeypoints.get(goodMatches[i].queryIdx).pt);
+          dstPoints.push(keypoints.get(goodMatches[i].trainIdx).pt);
+        }
+
+        // Convert points to Mat
+        const srcMat = cv.matFromArray(srcPoints.length, 1, cv.CV_32FC2, srcPoints);
+        const dstMat = cv.matFromArray(dstPoints.length, 1, cv.CV_32FC2, dstPoints);
+
+        // Find homography
+        const mask = new cv.Mat();
+        const H = cv.findHomography(srcMat, dstMat, cv.RANSAC, 5, mask);
+
+        // Use homography to check for object presence
+        log.innerText += `, homography ${H.empty ? 'empty' : 'yeah!'}`
+        if (!H.empty()) {
+          const hMask = new cv.Mat();
+          cv.findHomography(srcMat, dstMat, cv.RANSAC, 5, hMask);
+
+          // Count inliers
+          let inliers = 0;
+          for (let i = 0; i < hMask.rows; i++) {
+            if (hMask.data[i] === 1) {
+              inliers++;
+            }
+          }
+
+          // If enough inliers, consider the object found
+          log.innerText += `, ${inliers} good`
+          if (inliers > 10) {
+
+        const rectColor = new cv.Scalar(0, 255, 0, 255); // Green rectangle
+        const rectPoints = cv.matFromArray(4, 1, cv.CV_32FC2, [
+          0, 0,
+          referenceImage.cols, 0,
+          referenceImage.cols, referenceImage.rows,
+          0, referenceImage.rows
+        ]);
+
+            const perspectivePoints = new cv.Mat();
+        cv.perspectiveTransform(rectPoints, perspectivePoints, H);
+
+        // Draw rectangle around the detected object
+        const pointsData = perspectivePoints.data32F;
+        cv.line(output, new cv.Point(pointsData[0], pointsData[1]), new cv.Point(pointsData[2], pointsData[3]), rectColor, 2);
+        cv.line(output, new cv.Point(pointsData[2], pointsData[3]), new cv.Point(pointsData[4], pointsData[5]), rectColor, 2);
+        cv.line(output, new cv.Point(pointsData[4], pointsData[5]), new cv.Point(pointsData[6], pointsData[7]), rectColor, 2);
+        cv.line(output, new cv.Point(pointsData[6], pointsData[7]), new cv.Point(pointsData[0], pointsData[1]), rectColor, 2);
+
+        rectPoints.delete();
+        perspectivePoints.delete();
+          }
+
+          hMask.delete();
+        }
+
+        srcMat.delete();
+        dstMat.delete();
+        H.delete();
+        mask.delete();
+      }
+
+      const outputRect = get('outputRect');
+      cv.imshow(outputRect, output2);
+
+      cv.imshow(outputCanvas, gray);
+      cv.imshow(matchesDebugRenderingOutputCanvas, output);
+
+      src.delete()
+      gray.delete()
+      matches.delete();
+      output.delete();
+      keypoints.delete()
+      descriptors.delete()
+      newOrb.delete()
+
+      if(!lively.allParents(lively.query(this, '*'), [], true).includes(document.body)) {
+        lively.warn('BREAK')
+        referenceImage.delete();
+        referenceKeypoints.delete();
+        referenceDescriptors.delete();
+        matcher.delete()
+        orb.delete()
+        cap.delete()
+      } else {
+        requestAnimationFrame(processVideo);
+      }
+    }
+
+    processVideo();
+  }
+}
+
+run.call(this)
+</script>
+
